騒音防止ボルト固定式　CSNBB

騒音防止ボルト固定式
型 式
CSNBB
分類
一般溝用ボルト固定
仕様
ローレット加工
バー形状
フラットバー4mm
適用荷重
T20　T14　T6　T2　歩道
強度区分
一般タイプ
備考
公共建築協会評価対象製品
適用荷重(横/側） 溝幅 型式記号 高さ 本体価格
（円/枚）		 受枠価格
（円/両1m）		 DXF DWG JWW PDF
T-6/T-14 100 CSNBB-15-1_P=30 15 29,200 13,400 dxf dwg jww pdf
T-20 100 CSNBB-20-1_P=30 20 32,800 14,400 dxf dwg jww pdf
T-20 100 CSNBB-25-1_P=30 25 37,100 15,200 dxf dwg jww pdf
歩道/T-2 150 CSNBB-15-1.5_P=30 15 33,200 13,400 dxf dwg jww pdf
T-2/T-14 150 CSNBB-20-1.5_P=30 20 36,500 14,400 dxf dwg jww pdf
T-14/T-20 150 CSNBB-25-1.5_P=30 25 41,300 15,200 dxf dwg jww pdf
T-20 150 CSNBB-32-1.5_P=30 32 49,900 16,800 dxf dwg jww pdf
歩道 200 CSNBB-15-2_P=30 15 38,500 13,400 dxf dwg jww pdf
歩道/T-2 200 CSNBB-20-2_P=30 20 44,300 14,400 dxf dwg jww pdf
T-2/T-6 200 CSNBB-25-2_P=30 25 49,600 15,200 dxf dwg jww pdf
T-14/T-20 200 CSNBB-32-2_P=30 32 59,900 16,800 dxf dwg jww pdf
T-20 200 CSNBB-38-2_P=30 38 68,000 18,600 dxf dwg jww pdf
歩道 250 CSNBB-15-2.5_P=30 15 42,800 13,400 dxf dwg jww pdf
歩道 250 CSNBB-20-2.5_P=30 20 50,100 14,400 dxf dwg jww pdf
歩道/T-2 250 CSNBB-25-2.5_P=30 25 57,300 15,200 dxf dwg jww pdf
T-2/T-6 250 CSNBB-32-2.5_P=30 32 67,600 16,800 dxf dwg jww pdf
T-6/T-14 250 CSNBB-38-2.5_P=30 38 77,900 18,600 dxf dwg jww pdf
T-20 250 CSNBB-50-2.5_P=30 50 95,700 20,800 dxf dwg jww pdf
歩道 300 CSNBB-15-3_P=30 15 48,100 13,400 dxf dwg jww pdf
歩道 300 CSNBB-20-3_P=30 20 58,700 14,400 dxf dwg jww pdf
歩道/T-2 300 CSNBB-25-3_P=30 25 65,500 15,200 dxf dwg jww pdf
T-2 300 CSNBB-32-3_P=30 32 77,900 16,800 dxf dwg jww pdf
T-2/T-6 300 CSNBB-38-3_P=30 38 90,700 18,600 dxf dwg jww pdf
T-14/T-20 300 CSNBB-50-3_P=30 50 114,300 20,800 dxf dwg jww pdf
歩道 350 CSNBB-15-3.5_P=30 15 52,700 13,400 dxf dwg jww pdf
歩道 350 CSNBB-20-3.5_P=30 20 64,400 14,400 dxf dwg jww pdf
歩道 350 CSNBB-25-3.5_P=30 25 70,500 15,200 dxf dwg jww pdf
歩道/T-2 350 CSNBB-32-3.5_P=30 32 84,800 16,800 dxf dwg jww pdf
T-2 350 CSNBB-38-3.5_P=30 38 97,700 18,600 dxf dwg jww pdf
T-14 350 CSNBB-50-3.5_P=30 50 118,300 20,800 dxf dwg jww pdf
歩道 400 CSNBB-15-4_P=30 15 57,900 13,400 dxf dwg jww pdf
歩道 400 CSNBB-20-4_P=30 20 72,200 14,400 dxf dwg jww pdf
歩道 400 CSNBB-25-4_P=30 25 82,600 15,200 dxf dwg jww pdf
歩道/T-2 400 CSNBB-32-4_P=30 32 96,800 16,800 dxf dwg jww pdf
T-2 400 CSNBB-38-4_P=30 38 112,700 18,600 dxf dwg jww pdf
T-2/T-6 400 CSNBB-50-4_P=30 50 138,700 20,800 dxf dwg jww pdf
歩道 450 CSNBB-15-4.5_P=30 15 62,200 13,400 dxf dwg jww pdf
歩道 450 CSNBB-20-4.5_P=30 20 79,300 14,400 dxf dwg jww pdf
歩道 450 CSNBB-25-4.5_P=30 25 89,800 15,200 dxf dwg jww pdf
歩道/T2 450 CSNBB-32-4.5_P=30 32 103,400 16,800 dxf dwg jww pdf
歩道/T2 450 CSNBB-38-4.5_P=30 38 121,000 18,600 dxf dwg jww pdf
T2/T6 450 CSNBB-50-4.5_P=30 50 144,300 20,800 dxf dwg jww pdf
T-14 100 CSNBB-15-1_P=22 15 33,200 13,400 dxf dwg jww pdf
T-20 100 CSNBB-20-1_P=22 20 38,200 14,400 dxf dwg jww pdf
T-20 100 CSNBB-25-1_P=22 25 47,200 15,200 dxf dwg jww pdf
T-2 150 CSNBB-15-1.5_P=22 15 38,900 13,400 dxf dwg jww pdf
T-14 150 CSNBB-20-1.5_P=22 20 46,500 14,400 dxf dwg jww pdf
T-20 150 CSNBB-25-1.5_P=22 25 55,600 15,200 dxf dwg jww pdf
T-20 150 CSNBB-32-1.5_P=22 32 65,400 16,800 dxf dwg jww pdf
歩道/T-2 200 CSNBB-15-2_P=22 15 45,800 13,400 dxf dwg jww pdf
T-2 200 CSNBB-20-2_P=22 20 57,000 14,400 dxf dwg jww pdf
T-6/T-14 200 CSNBB-25-2_P=22 25 67,500 15,200 dxf dwg jww pdf
T-20 200 CSNBB-32-2_P=22 32 79,800 16,800 dxf dwg jww pdf
T-20 200 CSNBB-38-2_P=22 38 91,100 18,600 dxf dwg jww pdf
歩道 250 CSNBB-15-2.5_P=22 15 52,700 13,400 dxf dwg jww pdf
歩道/T-2 250 CSNBB-20-2.5_P=22 20 65,700 14,400 dxf dwg jww pdf
T-2 250 CSNBB-25-2.5_P=22 25 75,900 15,200 dxf dwg jww pdf
T-6/T-14 250 CSNBB-32-2.5_P=22 32 89,300 16,800 dxf dwg jww pdf
T-14/T-20 250 CSNBB-38-2.5_P=22 38 107,200 18,600 dxf dwg jww pdf
T-20 250 CSNBB-50-2.5_P=22 50 128,300 20,800 dxf dwg jww pdf
歩道 300 CSNBB-15-3_P=22 15 61,700 13,400 dxf dwg jww pdf
歩道/T-2 300 CSNBB-20-3_P=22 20 74,900 14,400 dxf dwg jww pdf
T-2 300 CSNBB-25-3_P=22 25 87,300 15,200 dxf dwg jww pdf
T-2/T-6 300 CSNBB-32-3_P=22 32 102,000 16,800 dxf dwg jww pdf
T-14 300 CSNBB-38-3_P=22 38 120,800 18,600 dxf dwg jww pdf
T-20 300 CSNBB-50-3_P=22 50 150,500 20,800 dxf dwg jww pdf
歩道 350 CSNBB-15-3.5_P=22 15 66,400 13,400 dxf dwg jww pdf
歩道 350 CSNBB-20-3.5_P=22 20 81,500 14,400 dxf dwg jww pdf
歩道/T-2 350 CSNBB-25-3.5_P=22 25 94,800 15,200 dxf dwg jww pdf
T-2 350 CSNBB-32-3.5_P=22 32 113,700 16,800 dxf dwg jww pdf
T-2/T-6 350 CSNBB-38-3.5_P=22 38 131,200 18,600 dxf dwg jww pdf
T-14/T-20 350 CSNBB-50-3.5_P=22 50 159,700 20,800 dxf dwg jww pdf
歩道 400 CSNBB-15-4_P=22 15 73,900 13,400 dxf dwg jww pdf
歩道 400 CSNBB-20-4_P=22 20 90,900 14,400 dxf dwg jww pdf
歩道/T-2 400 CSNBB-25-4_P=22 25 96,200 15,200 dxf dwg jww pdf
T-2 400 CSNBB-32-4_P=22 32 125,100 16,800 dxf dwg jww pdf
T-2 400 CSNBB-38-4_P=22 38 145,900 18,600 dxf dwg jww pdf
T-14 400 CSNBB-50-4_P=22 50 180,300 20,800 dxf dwg jww pdf
歩道 450 CSNBB-15-4.5_P=22 15 77,100 13,400 dxf dwg jww pdf
歩道 450 CSNBB-20-4.5_P=22 20 96,600 14,400 dxf dwg jww pdf
歩道 450 CSNBB-25-4.5_P=22 25 113,500 15,200 dxf dwg jww pdf
歩道/T2 450 CSNBB-32-4.5_P=22 32 137,360 16,800 dxf dwg jww pdf
T2 450 CSNBB-38-4.5_P=22 38 159,900 18,600 dxf dwg jww pdf
T14/T6 450 CSNBB-50-4.5_P=22 50 194,300 20,800 dxf dwg jww pdf
T-14 100 CSNBB-15-1_P=15 15 40,500 13,400 dxf dwg jww pdf
T-20 100 CSNBB-20-1_P=15 20 51,300 14,400 dxf dwg jww pdf
T-20 100 CSNBB-25-1_P=15 25 63,000 15,200 dxf dwg jww pdf
T-2/T-14 150 CSNBB-15-1.5_P=15 15 49,200 13,400 dxf dwg jww pdf
T-20 150 CSNBB-20-1.5_P=15 20 59,500 14,400 dxf dwg jww pdf
T-20 150 CSNBB-25-1.5_P=15 25 66,400 15,200 dxf dwg jww pdf
T-20 150 CSNBB-32-1.5_P=15 32 84,300 16,800 dxf dwg jww pdf
T-2 200 CSNBB-15-2_P=15 15 58,400 13,400 dxf dwg jww pdf
T-2/T-14 200 CSNBB-20-2_P=15 20 74,600 14,400 dxf dwg jww pdf
T-14/T-20 200 CSNBB-25-2_P=15 25 87,400 15,200 dxf dwg jww pdf
T-20 200 CSNBB-32-2_P=15 32 102,100 16,800 dxf dwg jww pdf
T-20 200 CSNBB-38-2_P=15 38 119,700 18,600 dxf dwg jww pdf
歩道/T-2 250 CSNBB-15-2.5_P=15 15 67,100 13,400 dxf dwg jww pdf
T-2 250 CSNBB-20-2.5_P=15 20 83,400 14,400 dxf dwg jww pdf
T-2/T-14 250 CSNBB-25-2.5_P=15 25 97,000 15,200 dxf dwg jww pdf
T-14/T-20 250 CSNBB-32-2.5_P=15 32 115,700 16,800 dxf dwg jww pdf
T-20 250 CSNBB-38-2.5_P=15 38 136,400 18,600 dxf dwg jww pdf
T-20 250 CSNBB-50-2.5_P=15 50 173,000 20,800 dxf dwg jww pdf
歩道 300 CSNBB-15-3_P=15 15 77,800 13,400 dxf dwg jww pdf
歩道/T-2 300 CSNBB-20-3_P=15 20 94,300 14,400 dxf dwg jww pdf
T-2 300 CSNBB-25-3_P=15 25 114,400 15,200 dxf dwg jww pdf
T-14 300 CSNBB-32-3_P=15 32 138,200 16,800 dxf dwg jww pdf
T-20 300 CSNBB-38-3_P=15 38 158,000 18,600 dxf dwg jww pdf
T-20 300 CSNBB-50-3_P=15 50 200,300 20,800 dxf dwg jww pdf
歩道 350 CSNBB-15-3.5_P=15 15 84,800 13,400 dxf dwg jww pdf
歩道/T-2 350 CSNBB-20-3.5_P=15 20 105,600 14,400 dxf dwg jww pdf
T-2 350 CSNBB-25-3.5_P=15 25 125,700 15,200 dxf dwg jww pdf
T-2/T-6 350 CSNBB-32-3.5_P=15 32 148,300 16,800 dxf dwg jww pdf
T-14 350 CSNBB-38-3.5_P=15 38 171,700 18,600 dxf dwg jww pdf
T-20 350 CSNBB-50-3.5_P=15 50 214,000 20,800 dxf dwg jww pdf
歩道 400 CSNBB-15-4_P=15 15 94,700 13,400 dxf dwg jww pdf
歩道/T-2 400 CSNBB-20-4_P=15 20 119,100 14,400 dxf dwg jww pdf
歩道/T-2 400 CSNBB-25-4_P=15 25 141,400 15,200 dxf dwg jww pdf
T-2 400 CSNBB-32-4_P=15 32 168,900 16,800 dxf dwg jww pdf
T-6/T-14 400 CSNBB-38-4_P=15 38 190,800 18,600 dxf dwg jww pdf
T-20 400 CSNBB-50-4_P=15 50 243,900 20,800 dxf dwg jww pdf
歩道 450 CSNBB-15-4.5_P=15 15 102,600 13,400 dxf dwg jww pdf
歩道 450 CSNBB-20-4.5_P=15 20 129,600 14,400 dxf dwg jww pdf
歩道/T2 450 CSNBB-25-4.5_P=15 25 152,100 15,200 dxf dwg jww pdf
T2 450 CSNBB-32-4.5_P=15 32 182,100 16,800 dxf dwg jww pdf
T2/T6 450 CSNBB-38-4.5_P=15 38 210,100 18,600 dxf dwg jww pdf
T20 450 CSNBB-50-4.5_P=15 50 261,300 20,800 dxf dwg jww pdf
T-14 100 CSNBB-15-1_P=13 15 45,000 13,400 dxf dwg jww pdf
T-20 100 CSNBB-20-1_P=13 20 56,500 14,400 dxf dwg jww pdf
T-20 100 CSNBB-25-1_P=13 25 66,600 15,200 dxf dwg jww pdf
T-6/T-14 150 CSNBB-15-1.5_P=13 15 54,100 13,400 dxf dwg jww pdf
T-20 150 CSNBB-20-1.5_P=13 20 67,500 14,400 dxf dwg jww pdf
T-20 150 CSNBB-25-1.5_P=13 25 78,500 15,200 dxf dwg jww pdf
T-20 150 CSNBB-32-1.5_P=13 32 97,100 16,800 dxf dwg jww pdf
T-2 200 CSNBB-15-2_P=13 15 65,700 13,400 dxf dwg jww pdf
T-6/T-14 200 CSNBB-20-2_P=13 20 81,300 14,400 dxf dwg jww pdf
T-20 200 CSNBB-25-2_P=13 25 95,500 15,200 dxf dwg jww pdf
T-20 200 CSNBB-32-2_P=13 32 120,700 16,800 dxf dwg jww pdf
T-20 200 CSNBB-38-2_P=13 38 133,900 18,600 dxf dwg jww pdf
歩道/T-2 250 CSNBB-15-2.5_P=13 15 75,400 13,400 dxf dwg jww pdf
T-2 250 CSNBB-20-2.5_P=13 20 96,000 14,400 dxf dwg jww pdf
T-6/T-14 250 CSNBB-25-2.5_P=13 25 109,600 15,200 dxf dwg jww pdf
T-20 250 CSNBB-32-2.5_P=13 32 144,200 16,800 dxf dwg jww pdf
T-20 250 CSNBB-38-2.5_P=13 38 152,100 18,600 dxf dwg jww pdf
T-20 250 CSNBB-50-2.5_P=13 50 192,900 20,800 dxf dwg jww pdf
歩道 300 CSNBB-15-3_P=13 15 89,000 13,400 dxf dwg jww pdf
T-2 300 CSNBB-20-3_P=13 20 96,400 14,400 dxf dwg jww pdf
T-2/T-6 300 CSNBB-25-3_P=13 25 127,100 15,200 dxf dwg jww pdf
T-14/T-20 300 CSNBB-32-3_P=13 32 158,800 16,800 dxf dwg jww pdf
T-20 300 CSNBB-38-3_P=13 38 173,100 18,600 dxf dwg jww pdf
T-20 300 CSNBB-50-3_P=13 50 223,700 20,800 dxf dwg jww pdf
歩道 350 CSNBB-15-3.5_P=13 15 96,600 13,400 dxf dwg jww pdf
歩道/T-2 350 CSNBB-20-3.5_P=13 20 123,800 14,400 dxf dwg jww pdf
T-2 350 CSNBB-25-3.5_P=13 25 145,800 15,200 dxf dwg jww pdf
T-6/T-14 350 CSNBB-32-3.5_P=13 32 175,200 16,800 dxf dwg jww pdf
T-14/T-20 350 CSNBB-38-3.5_P=13 38 191,900 18,600 dxf dwg jww pdf
T-20 350 CSNBB-50-3.5_P=13 50 248,200 20,800 dxf dwg jww pdf
歩道 400 CSNBB-15-4_P=13 15 107,500 13,400 dxf dwg jww pdf
歩道/T-2 400 CSNBB-20-4_P=13 20 140,700 14,400 dxf dwg jww pdf
T-2 400 CSNBB-25-4_P=13 25 164,100 15,200 dxf dwg jww pdf
T-2/T-6 400 CSNBB-32-4_P=13 32 197,600 16,800 dxf dwg jww pdf
T-14 400 CSNBB-38-4_P=13 38 213,100 18,600 dxf dwg jww pdf
T-20 400 CSNBB-50-4_P=13 50 272,900 20,800 dxf dwg jww pdf
歩道 450 CSNBB-15-4.5_P=13 15 116,300 13,400 dxf dwg jww pdf
歩道/T2 450 CSNBB-20-4.5_P=13 20 152,000 14,400 dxf dwg jww pdf
歩道/T2 450 CSNBB-25-4.5_P=13 25 176,700 15,200 dxf dwg jww pdf
T2 450 CSNBB-32-4.5_P=13 32 215,200 16,800 dxf dwg jww pdf
T14/T6 450 CSNBB-38-4.5_P=13 38 235,100 18,600 dxf dwg jww pdf
T20 450 CSNBB-50-4.5_P=13 50 300,300 20,800 dxf dwg jww pdf
T-20 100 CSNBB-15-1_P=10 15 54,700 13,400 dxf dwg jww pdf
T-20 100 CSNBB-20-1_P=10 20 71,700 14,400 dxf dwg jww pdf
T-20 100 CSNBB-25-1_P=10 25 95,500 15,200 dxf dwg jww pdf
T-14/T-20 150 CSNBB-15-1.5_P=10 15 67,200 13,400 dxf dwg jww pdf
T-20 150 CSNBB-20-1.5_P=10 20 87,700 14,400 dxf dwg jww pdf
T-20 150 CSNBB-25-1.5_P=10 25 116,900 15,200 dxf dwg jww pdf
T-20 150 CSNBB-32-1.5_P=10 32 141,500 16,800 dxf dwg jww pdf
T-2/T-6 200 CSNBB-15-2_P=10 15 80,800 13,400 dxf dwg jww pdf
T-14/T-20 200 CSNBB-20-2_P=10 20 106,500 14,400 dxf dwg jww pdf
T-20 200 CSNBB-25-2_P=10 25 125,400 15,200 dxf dwg jww pdf
T-20 200 CSNBB-32-2_P=10 32 169,100 16,800 dxf dwg jww pdf
T-20 200 CSNBB-38-2_P=10 38 184,900 18,600 dxf dwg jww pdf
T-2 250 CSNBB-15-2.5_P=10 15 93,600 13,400 dxf dwg jww pdf
T-2/T-14 250 CSNBB-20-2.5_P=10 20 124,400 14,400 dxf dwg jww pdf
T-14/T-20 250 CSNBB-25-2.5_P=10 25 145,800 15,200 dxf dwg jww pdf
T-20 250 CSNBB-32-2.5_P=10 32 181,000 16,800 dxf dwg jww pdf
T-20 250 CSNBB-38-2.5_P=10 38 216,800 18,600 dxf dwg jww pdf
T-20 250 CSNBB-50-2.5_P=10 50 289,700 20,800 dxf dwg jww pdf
歩道/T-2 300 CSNBB-15-3_P=10 15 106,900 13,400 dxf dwg jww pdf
T-2 300 CSNBB-20-3_P=10 20 139,600 14,400 dxf dwg jww pdf
T-6/T-14 300 CSNBB-25-3_P=10 25 169,800 15,200 dxf dwg jww pdf
T-20 300 CSNBB-32-3_P=10 32 212,000 16,800 dxf dwg jww pdf
T-20 300 CSNBB-38-3_P=10 38 247,200 18,600 dxf dwg jww pdf
T-20 300 CSNBB-50-3_P=10 50 331,600 20,800 dxf dwg jww pdf
歩道/T-2 350 CSNBB-15-3.5_P=10 15 119,900 13,400 dxf dwg jww pdf
T-2 350 CSNBB-20-3.5_P=10 20 160,600 14,400 dxf dwg jww pdf
T-2/T-6 350 CSNBB-25-3.5_P=10 25 188,600 15,200 dxf dwg jww pdf
T-14/T-20 350 CSNBB-32-3.5_P=10 32 234,800 16,800 dxf dwg jww pdf
T-20 350 CSNBB-38-3.5_P=10 38 265,400 18,600 dxf dwg jww pdf
T-20 350 CSNBB-50-3.5_P=10 50 376,100 20,800 dxf dwg jww pdf
歩道 400 CSNBB-15-4_P=10 15 145,800 13,400 dxf dwg jww pdf
歩道/T-2 400 CSNBB-20-4_P=10 20 180,700 14,400 dxf dwg jww pdf
T-2 400 CSNBB-25-4_P=10 25 212,400 15,200 dxf dwg jww pdf
T-14 400 CSNBB-32-4_P=10 32 263,600 16,800 dxf dwg jww pdf
T-20 400 CSNBB-38-4_P=10 38 307,000 18,600 dxf dwg jww pdf
T-20 400 CSNBB-50-4_P=10 50 418,100 20,800 dxf dwg jww pdf
歩道 450 CSNBB-15-4.5_P=10 15 145,700 13,400 dxf dwg jww pdf
歩道/T-2 450 CSNBB-20-4.5_P=10 20 195,500 14,400 dxf dwg jww pdf
T2 450 CSNBB-25-4.5_P=10 25 230,500 15,200 dxf dwg jww pdf
T6 450 CSNBB-32-4.5_P=10 32 287,400 16,800 dxf dwg jww pdf
T14 450 CSNBB-38-4.5_P=10 38 313,400 18,600 dxf dwg jww pdf
T20 450 CSNBB-50-4.5_P=10 50 431,600 20,800 dxf dwg jww pdf

関連商品

最近チェックした製品

CSNBBに関するお問い合わせ
